Concepts & Conventions

Before building your first scene, it helps to know the handful of conventions PoreScene assumes throughout. Following them keeps scripts reuseable and – just as importantly – keeps the rendered geometries physically on scale: the whole scene traces back to a real, SI-based dimension.

Coordinate system and axis orientation

PoreScene renders with Blender’s Cycles engine and therefore inherits Blender’s right-handed, Z-up coordinate system: x and y span the horizontal plane and z points up. The calibrated axes drawn by Scene.create_axes() follow the same handedness, with ticks increasing from the domain origin along each direction.

PoreScene’s right-handed, Z-up coordinate system. The calibrated x, y, and z axes originate at the domain corner and carry the physical scale in the configured display unit, while z points up.

If the default viewing angle does not suit your sample, the camera can be rotated around the scene: Scene.rotate_azimuth() orbits the camera (and the lights) around the vertical z axis by a given azimuth angle in degrees, keeping it aimed at the scene center.

Units

Internal units

PoreScene stores all physical quantities in SI base units, which is especially important for lengths that are therefore always given in meters. This holds rigorously true in all parts of the package, which ensures that generated visualizations are always on scale:

• the domain dimensions passed to Scene.from_json(),

• pore and throat radii (PoreNetwork.pore_radius, PoreNetwork.throat_radius),

• pore positions and every coordinate imported from a .mat file.

Keeping the internal representation in meters makes the numbers you pass unambiguous regardless of the length scale of your sample – from nanometer-scale membranes to millimeter-scale packings.

Display units

While the internal storage is in meters, the units shown on the axes are configurable. The PoreScene configuration porescene.json accepts a unit_display key that converts axis ticks into the desired length scale. It defaults to "MICRO" (micrometers, µm), which suits most tomographic samples. PoreScene understands the full metric range, from QUETTA (10³⁰) down to QUECTO (10^-30), so the same data can be labeled in nm, µm, mm, etc., without touching the geometry. Internally the tick values are converted from meters to the chosen display unit by a scale factor.

As example, in case the axis needs to be shown in millimeters, the porescene.json can be adjusted accordingly:

porescene.json

{
   "axes": {
      "unit_display": "MILLI"
   }
}

Scene scale vs. physical scale

The geometry is normalized into a fixed bounding box for rendering: the longest domain edge is mapped onto a bounding box of constant size, and the remaining edges are scaled by the same factor so the aspect ratio is preserved. As a result, Blender scene units are not meters – the physical scale lives on the calibrated axes, which are annotated in the chosen display unit. This decoupling makes that samples of very different absolute size render into comparable, publication-ready figures.

Scene components

PoreScene is modular: a scene is composed from independent components rather than produced in one monolithic step. Creating a Scene – either empty or from a configuration with Scene.from_json() – sets up only the camera and lighting. Every visible element is then added explicitly, so you build exactly the figure you need and nothing that you do not.

Once the scene exists, elements are added through dedicated create_* methods:

• Scene.create_spheres() – a sphere for each pore (the ball of the stick-and-ball representation).

• Scene.create_cylinders() – a cylinder for each throat (the stick).

• Scene.create_clusters() – watershed pore clusters loaded from a file.

• Scene.create_cells() – Voronoi cells of a volume tessellation.

• Scene.create_solid() – the solid microstructure, e.g. from tomographic imaging.

• Scene.create_void() – the void space as a single 3D object.

• Scene.create_axes() – calibrated, on-scale axes with ticks and labels.

A pore network in stick-and-ball form with axes is therefore assembled from a few explicit calls (note that coloring etc. needs additional steps):

from pathlib import Path

from porescene.model import PoreNetwork
from porescene.scene import Scene

pth_data = Path.cwd()

pn = PoreNetwork.from_mat(pth_data / "pnm.mat")
sc = Scene.from_json(pn.extent, pth_data / "porescene.json")

sc.create_axes()
sc.create_spheres(pn.pore_position, pn.pore_radius)
sc.create_cylinders(pn.throat_position, pn.throat_radius)
sc.render(pth_data / "network.png")

Because scene elements are added independently, the same scene can freely combine representations – for example wrapping the stick and ball representation with the solid – and only the elements you add are present in the final render.

Note

The higher-level workers in porescene.worker build on exactly these methods: they assemble the required geometry (such as throat end points) and then call the matching create_* methods for you.
